SPECIFICATION: |
|
MODEL |
BMT
330FA/ 330FANC |
|
CAPACITY |
330 mm
330 x 330 mm |
|
BLADE SIZE |
34 x 1.1 x 4100 mm |
|
BLADE SPEED |
50HZ: 20~71m/min. , 60HZ: 25~85m/min. |
|
MAIN MOTOR |
5HP (3.7kw) x 4P |
|
HYDRAULIC MOTOR |
1HP (0.74kw) x 4P |
|
COOLANT MOTOR |
1/6HP (124w) x 4P |
|
HYDRAULIC TANK |
40Liters |
|
COOLANT TANK |
60Liters |
|
LOAD CAPACITY |
1750KGS |
|
CROLLER STAND LOADING CAPACITY |
1250KGS |
|
MINIMUM RESIDUAL WORK LENGTH |
50mm |
|
BUNDLE CUTTING (W x H) |
150~250 x 120~180mm |
|
CUT OFF LENGTH |
Over 10mm |
|
NO. OF SET CUTS |
1~9999 |
|
FEEDING STROKE |
400mm |
|
MINIMUM NO MATERIAL DETECTING |
32mm |
|
TABLE HEIGHT |
760mm |
|
PACKING SIZE (L x Wx H) |
2210 x 2290 x 1890mm |
|
MACHINE WEIGHT (N.W./ G.W.) |
1700KGS/ 1850KGS |
|
*The above specifications are subject to change without
prior notice. |
